The Attack DPX 100 Profi is a powerful wood gasification boiler for the efficient combustion of split logs. With a rated output of approximately 100 kW, the unit is ideally suited for larger residential buildings, agricultural operations, or commercial applications. The boiler operates on the wood gasification principle for clean and efficient energy generation.
⭐ Highlights / Advantages
- ⭐ Wood gasification boiler with approx. 98.2 kW rated output for large heating systems
- ⭐ Energy efficiency class A+ for economical operation
- ⭐ Optimized for split logs with high combustion efficiency
- ⭐ Robust construction for long-lasting use in continuous operation
- ⭐ Suitable for combination with large buffer tanks
Application Area & Target Audience
The Attack DPX 100 Profi is aimed at:
- Private customers with high heat demand (e.g., multi-family houses)
- HVAC specialist companies for demanding heating projects
- Commercial and agricultural applications
- Renovations as well as new builds with wood heating
Advantages in Everyday Use
The wood gasification boiler enables the efficient use of split logs as a renewable fuel. Through optimized combustion, stable operation is achieved with simultaneously reduced emissions. In combination with a sufficiently sized buffer tank, a comfortable and low-maintenance heating system is created.
Technology & Features
The Attack DPX 100 Profi operates on the wood gasification principle with a separate combustion zone. The air supply is via primary and secondary air flaps, which are adjusted for optimal gasification. For efficient heat transfer, the boiler is equipped with a tube heat exchanger that can be cleaned regularly.
For safe operation, the following components are required:
- Thermal discharge safety device
- Return temperature elevation (e.g., mixing system)
- Expansion vessel and safety valve
Operation is manual with split logs as the primary fuel. :contentReference[oaicite:0]{index=0}
Efficiency & Environment
The boiler achieves an energy efficiency class of A+ as well as a utilization rate of up to 81.4 % at rated output. The seasonal space heating efficiency is 78 %. :contentReference[oaicite:1]{index=1}
Through the wood gasification technology, clean combustion with reduced emissions is achieved:
- Dust: 40 mg/m³
- CO: 270 mg/m³
- NOx: 198 mg/m³
Compatibility & System Integration
The Attack DPX 100 Profi must be integrated into a suitable heating system:
- Buffer tank (recommended ≥ 4330 liters)
- Radiator or underfloor heating systems
- Hydraulic integration with return temperature elevation
Operation without a buffer tank is not intended by the manufacturer and can significantly reduce efficiency. :contentReference[oaicite:2]{index=2}
Technical Data
| Manufacturer |
Attack |
| Model |
DPX 100 Profi |
| Product Type |
Wood gasification boiler |
| Rated Output |
98.2 kW |
| Energy Efficiency Class |
A+ |
| Efficiency |
81.4 % |
| Seasonal Efficiency |
78 % |
| Fuel |
Split logs ≤ 25 % moisture |
| Electrical Power Consumption |
0.103 kW |
| Standby Consumption |
0.003 kW |
| EEI |
114 |
| Operating Mode |
manual |
| Height |
1,575 mm |
| Width |
915 mm |
| Depth |
1,890 mm |
Scope of Delivery
not specified in the data sheet
Accessories & System Recommendations
For safe and efficient operation, the following accessories are recommended:
Matching system components
Installation & Safety Notes
Installation must be carried out exclusively by a qualified specialist company. The chimney must meet the required draft conditions; otherwise, function may be impaired. The operating pressure in the heating system must not exceed 2.5 bar. :contentReference[oaicite:3]{index=3}
For a long service life, a return temperature of over 65 °C must be ensured. :contentReference[oaicite:4]{index=4}
FAQ
Which fuel is used?
The boiler is designed for split logs with a maximum moisture content of 25%.
Is a buffer tank required?
Yes, the manufacturer recommends a buffer tank with a minimum volume of 4330 liters.
What is the output of the boiler?
The rated output is 98.2 kW.
What energy efficiency class does the unit have?
The Attack DPX 100 Profi achieves energy efficiency class A+.
What is the efficiency?
The efficiency is approximately 81.4% at rated output.
Who is allowed to install the boiler?
Installation must be carried out by an HVAC specialist company to ensure safety and warranty.
